HEWI Shower grab rail


Product information

  • Made of high-quality chrome-look coated polyamide that is warm to touch
  • Horizontally arranged bars connected at right-angles, with steel fixing roses
  • Used in the shower and bathtub area to hold onto and for support
  • Horizontal lengths 762 mm
  • 88 mm deep, clear distance to the wall 55 mm, bar diameter 33 mm, rose diameter 70 mm
  • With continuous, corrosion-resistant steel core
  • For wall mounting with special HEWI fixing materials and roses
  • Can be mounted on the right and left side
  • Suitable for all HEWI hook-in seats

Technical specifications

Material and colour
Chrome-look coated polyamide




HEWI colour chart
Installation instructions (de, en, fr, nl, it, es, pl, no, dk, se)
2D drawing
Product Data Sheet
Tender specifications
Download everything
Technical information subject to alteration
