Hinged seat

Article number 801.51.207 99

HEWI folding seat
Polyamide, high gloss, Width 378 mm, Depth 408 mm, Seat surface 345 mm wide, tested up to 200 kg when used with HEWI fixing material, Recommended maximum weight of the user: 150 kg.

Current color: 99 (pure white)

Declaration of consent for use

I have read the conditions for using the media download and hereby accept them

In what size would you like to receive the images?

Gallery

600 x 450 px

460 x 460 px

1000 x 1000 px

Original

Original size

How would you like to receive the images?

Download By email

Downloads and documents

Product data sheet

Add to the comparison list comparison list

EAN

4014885644408

Colour

99pure white

Material Seat/ Backrest

Polyamide

Material

Polyamide

Range 801 Hinged seat
- Construction of bars and seat
- for safe sitting in the shower area - with space-saving fold-up seat
- Mounting on the wall with wall-specific HEWI fixing material
- Sealing tape and sealing rods for sealing the mounting points according to DIN 18534 are included in the delivery
- Concealed mounting
- tested up to 200 kg when used with HEWI fixing material
- Recommended maximum weight of the user: 150 kg
- 378 mm wide, 408 mm deep
- seat 345 mm wide
- made of high-gloss polyamide in all HEWI colours
- With corrosion-resistant steel core
- Wall plates made of polyamide with integrated steel core

Design awards

Awarded by

Downloads

2D drawing	DXF
Drilling pattern	JPG
Product data sheet	PDF
Installation instructions	PDF
Cleaning and Care Instructions	PDF
