Article number 801.50.130 99
HEWI folding support handle
Polyamide, high gloss, Projection 900 mm, tested up to 150 kg when used with HEWI fixing material, Recommended maximum weight of the user: 150 kg, is produced in accordance with CE and UKCA Regulation (EU) 2017/745 on medical devices, fulfils the ÖNORM B1600/1601 requirements.
Show more Polyamide, high gloss, Projection 900 mm, tested up to 150 kg when used with HEWI fixing material, Recommended maximum weight of the user: 150 kg, is produced in accordance with CE and UKCA Regulation (EU) 2017/745 on medical devices, fulfils the ÖNORM B1600/1601 requirements.
Current color: 99 (pure white)
EAN
4014884935705
article group
Hinged support rail
Function
hinged/ rotatable
Version
suitable for both sides
Size
900 mm
Colour
Variant
without additional function
Assembly
fixed
Material
Polyamide
Insert
Steel core
Supplied only with wall-specific HEWI fixing material (Stainless steel).
Hinged support rail, rotatable of the 801 series
- Two parallel rails, arranged on top of each other, bars joined together by a connecting arch
- is used for holding and supporting - with continuous, corrosion resistant steel core and wall plate made of polyamide with integrated steel core
- Can be folded upwards and, folded downwards with braking mechanism, in raised position can be turned to left or right towards the wall
- Mounting on the wall with wall-specific HEWI mounting material (to be ordered separately)
Sealing tape for sealing the fixing points is included in the delivery
- Concealed mounting
- tested up to 150 kg when used with HEWI fixing material
- Recommended maximum weight of the user: 150 kg
- Projection 900 mm , Height 259 mm and width 78 mm , Rail 33 mm in diameter
- made of high-gloss polyamide according to HEWI colour chart
- Toilet roll holder 801.50.011, - Toilet flushing mechanism (radio) 801.50.060 and floor supports 950.50.021XA and 950.50.023XA retrofittable
- is produced in accordance with CE and UKCA Regulation (EU) 2017/745 on medical devices
- fulfils the requirements of ÖNORM B1600/1601
- Two parallel rails, arranged on top of each other, bars joined together by a connecting arch
- is used for holding and supporting - with continuous, corrosion resistant steel core and wall plate made of polyamide with integrated steel core
- Can be folded upwards and, folded downwards with braking mechanism, in raised position can be turned to left or right towards the wall
- Mounting on the wall with wall-specific HEWI mounting material (to be ordered separately)
Sealing tape for sealing the fixing points is included in the delivery
- Concealed mounting
- tested up to 150 kg when used with HEWI fixing material
- Recommended maximum weight of the user: 150 kg
- Projection 900 mm , Height 259 mm and width 78 mm , Rail 33 mm in diameter
- made of high-gloss polyamide according to HEWI colour chart
- Toilet roll holder 801.50.011, - Toilet flushing mechanism (radio) 801.50.060 and floor supports 950.50.021XA and 950.50.023XA retrofittable
- is produced in accordance with CE and UKCA Regulation (EU) 2017/745 on medical devices
- fulfils the requirements of ÖNORM B1600/1601
