Article number 801.50B2002
HEWI ICONIC folding support handle
Polyamide, matt, Three-coloured folding support handle, Cantilever: 55 (aqua blue), Wall plate: 50 (steel blue), Support: 74 (apple green), projection 600 mm , tested up to 150 kg when used with HEWI fixing material, Recommended maximum weight of the user: 150 kg, Produced in accordance with Regulation (EU) 2017/745 on medical devices, fulfils the DIN 18040 requirements.
Show more Polyamide, matt, Three-coloured folding support handle, Cantilever: 55 (aqua blue), Wall plate: 50 (steel blue), Support: 74 (apple green), projection 600 mm , tested up to 150 kg when used with HEWI fixing material, Recommended maximum weight of the user: 150 kg, Produced in accordance with Regulation (EU) 2017/745 on medical devices, fulfils the DIN 18040 requirements.
EAN
4014885667209
article group
Hinged support rail
Hilfsmittelnummer
04.40.05.1256
Function
hinged
Version
suitable for both sides
Size
600 mm
Material
Polyamide, mat
Insert
Steel core
Series 801 ICONIC Hinged support rail
- Three-coloured folding support handle
- Made of matt polyamide
- Cantilever: 55 (aqua blue), Wall plate: 50 (steel blue), Support: 74 (apple green)
- Two parallel rails, arranged on top of each other, bars joined together by a connecting arch
- is used for holding and supporting - with continuous, corrosion resistant steel core and wall plate made of polyamide with integrated steel core
- Can be folded upwards and folded downwards with braked movement
- Mounting on the wall with wall-specific HEWI mounting material (to be ordered separately)
Sealing tape for sealing the fixing points is included in the delivery
- Concealed mounting
- tested up to 150 kg when used with HEWI fixing material
- Recommended maximum weight of the user: 150 kg
- Projection 600 mm , Height 259 mm and width 78 mm , Rail 33 mm in diameter
- Toilet roll holder 801.50B011, Toilet flushing mechanism (radio) 801.50B060 and floor supports 950.50.021XA and 950.50.023XA retrofittable
- Produced in accordance with Regulation (EU) 2017/745 on medical devices
- Fulfils the DIN 18040 requirements
- Three-coloured folding support handle
- Made of matt polyamide
- Cantilever: 55 (aqua blue), Wall plate: 50 (steel blue), Support: 74 (apple green)
- Two parallel rails, arranged on top of each other, bars joined together by a connecting arch
- is used for holding and supporting - with continuous, corrosion resistant steel core and wall plate made of polyamide with integrated steel core
- Can be folded upwards and folded downwards with braked movement
- Mounting on the wall with wall-specific HEWI mounting material (to be ordered separately)
Sealing tape for sealing the fixing points is included in the delivery
- Concealed mounting
- tested up to 150 kg when used with HEWI fixing material
- Recommended maximum weight of the user: 150 kg
- Projection 600 mm , Height 259 mm and width 78 mm , Rail 33 mm in diameter
- Toilet roll holder 801.50B011, Toilet flushing mechanism (radio) 801.50B060 and floor supports 950.50.021XA and 950.50.023XA retrofittable
- Produced in accordance with Regulation (EU) 2017/745 on medical devices
- Fulfils the DIN 18040 requirements
