Article number 950.50.61140
HEWI Mono hinged support rail, mobile
with a horizontal, flat handle gripping level, rail made of rectangular profile, 40 mm wide and 30 mm height, projection 600 mm, bracket 181 mm high and 130 mm wide, weight capacity to 100 kg to DIN 18040, made of metal, high-quality chrome-plated, wall plate cover made of environmentally friendly chrome-look coated polyamide, produced in accordance with CE- and UKCA-Regulation (EU) 2017/745 on medical devices. Mounting only possible in conjunction with the matching wall plate. Wall Specific HEWI Fixing material to be ordered separately.
Show more
with a horizontal, flat handle gripping level, rail made of rectangular profile, 40 mm wide and 30 mm height, projection 600 mm, bracket 181 mm high and 130 mm wide, weight capacity to 100 kg to DIN 18040, made of metal, high-quality chrome-plated, wall plate cover made of environmentally friendly chrome-look coated polyamide, produced in accordance with CE- and UKCA-Regulation (EU) 2017/745 on medical devices. Mounting only possible in conjunction with the matching wall plate. Wall Specific HEWI Fixing material to be ordered separately.
![CE-Kennzeichen CE-Kennzeichen](https://catalog.hewi.com/storage/downloads/ce_kennzeichen.png)
EAN
4014884981832
Version
suitable for both sides
Function
hinged
Size
600 mm
Variant
without additional function
Material
Chrome
Assembly
mobile
Supplied only with wall-specific HEWI fixing material (Stainless steel).
Mono mobile hinged support rail
- for easy and flexible retrofitting on existing, preassembled mounting plate: 950.50.01440, must be ordered separately
- for mobile use
- with a horizontal, two-dimensional gripping level
- for holding on to and providing support
- rail made of rectangular profile, 40 mm wide and 30 mm, provides a wide support surface and large radii for pleasant gripping
- 600 mm projection, bracket 181 mm high and 130 mm wide
- can be folded upwards and, folded downwards with braking mechanism
- made of metal, high-quality chrome-plated
- wall plate cover made of chrome-look coated polyamide
- tool-free and quick installation by means of short, simple hanging
- secured against unintentional removal
- unlocking for flexible use by spring actuation
- with toilet roll holder 950.50.01150, toilet roll holder with WC flushing mechanism 950.50.07290 (right), 950.50.07390 (left) and arm pad 950.50.03192 for retrofitting
- produced in accordance with CE- and UKCA-Regulation (EU) 2017/745 on medical devices
- fulfils the DIN 18040 requirements
- weight capacity 100 kg
- for easy and flexible retrofitting on existing, preassembled mounting plate: 950.50.01440, must be ordered separately
- for mobile use
- with a horizontal, two-dimensional gripping level
- for holding on to and providing support
- rail made of rectangular profile, 40 mm wide and 30 mm, provides a wide support surface and large radii for pleasant gripping
- 600 mm projection, bracket 181 mm high and 130 mm wide
- can be folded upwards and, folded downwards with braking mechanism
- made of metal, high-quality chrome-plated
- wall plate cover made of chrome-look coated polyamide
- tool-free and quick installation by means of short, simple hanging
- secured against unintentional removal
- unlocking for flexible use by spring actuation
- with toilet roll holder 950.50.01150, toilet roll holder with WC flushing mechanism 950.50.07290 (right), 950.50.07390 (left) and arm pad 950.50.03192 for retrofitting
- produced in accordance with CE- and UKCA-Regulation (EU) 2017/745 on medical devices
- fulfils the DIN 18040 requirements
- weight capacity 100 kg
