Article number 801.01.500}
HEWI tilting mirror, motorised
Composite mirror with integrated splinter protection, rectangular, Width 600 mm, Height 540 mm, the mirror can be motorised and tilted by max. 28°, Control via maintenance-free wireless wall switch, CE marking according to EMC 2004/108/EC, Suitable for power grids with mains voltages between 100 and 240 V and mains frequencies of 50 and 60 Hz and 277 V for the USA.
Show more
Composite mirror with integrated splinter protection, rectangular, Width 600 mm, Height 540 mm, the mirror can be motorised and tilted by max. 28°, Control via maintenance-free wireless wall switch, CE marking according to EMC 2004/108/EC, Suitable for power grids with mains voltages between 100 and 240 V and mains frequencies of 50 and 60 Hz and 277 V for the USA.
EAN
4014885690603
With LED
No
Version
with shatter protection film
Kind
- Adjustable mirrors
Size
600 x 540 mm
Material
Glass
Range 801 Adjustable mirror, motorised
- Rectangular crystal mirror with polished edges and integrated anti-shatter foil
- The motorised mirror can be tilted by a maximum of 28° and can therefore be used in a standing or sitting position
- for wall mounting
- 600 mm wide, 540 mm high and 6 mm thick
- Mirrors made of laminated glass
- CE marking in accordance with EMC 2004/108/EV
- Suitable for power grids with mains voltages between 100 and 240 V and mains frequencies of 50 and 60
Hz and 277 V for the USA
- Control via maintenance-free wireless wall switch
- Wireless wall switch can be freely positioned on the wall via adhesive mounting or integrated into a 55 mm frame in the electrical installation
- Rectangular crystal mirror with polished edges and integrated anti-shatter foil
- The motorised mirror can be tilted by a maximum of 28° and can therefore be used in a standing or sitting position
- for wall mounting
- 600 mm wide, 540 mm high and 6 mm thick
- Mirrors made of laminated glass
- CE marking in accordance with EMC 2004/108/EV
- Suitable for power grids with mains voltages between 100 and 240 V and mains frequencies of 50 and 60
Hz and 277 V for the USA
- Control via maintenance-free wireless wall switch
- Wireless wall switch can be freely positioned on the wall via adhesive mounting or integrated into a 55 mm frame in the electrical installation
Design awards
Awarded by
Downloads
| 2D drawing | DXF | |
| Product data sheet | ||
| Installation instructions | ||
| Cleaning and Care Instructions |
Documents
| Colour Chart | Link |
