24" (610 mm)
Article number 950.36US1390 99
HEWI Grab bar (USA) from System 800 K
straight rail, with corrosion-protected steel core throughout, outside dimension 24 inch (610 mm), rail diameter 1 5/16 inch (33 mm), 2 13/16 inch (71 mm) deep, rose diameter 3 1/8 inch (80 mm), cap height 1/2 inch (13 mm), includes non-corroding HEWI fixing material, maximum loading capacity 250 lbs (113 kg), made of high-quality polyamide in HEWI colour 99 (pure white), 95 (stone gray), 92 (anthracite gray), 90 (jet black), 86 (sand), 84 (umber) and 33 (ruby red), meets the requirements of 2010 ADA standards and ICC/ANSI A117.1-2017.
Show more straight rail, with corrosion-protected steel core throughout, outside dimension 24 inch (610 mm), rail diameter 1 5/16 inch (33 mm), 2 13/16 inch (71 mm) deep, rose diameter 3 1/8 inch (80 mm), cap height 1/2 inch (13 mm), includes non-corroding HEWI fixing material, maximum loading capacity 250 lbs (113 kg), made of high-quality polyamide in HEWI colour 99 (pure white), 95 (stone gray), 92 (anthracite gray), 90 (jet black), 86 (sand), 84 (umber) and 33 (ruby red), meets the requirements of 2010 ADA standards and ICC/ANSI A117.1-2017.
Current color: 99 (pure white)
EAN
4014885533290
article group
Support rail
Version
continuous steel core/ steel fixing roses
Colour
Material
Polyamide
Grab bar (USA) from System 800 K
- straight rail with supports straight to the wall and roses
- for holding onto and as a support
- with corrosion-protected steel core throughout
- length 24 inch (610 mm), rail diameter of rail 1 5/16 inch (33 mm), 2 13/16 inch (71 mm) deep
- wall connection with discreet supports perpendicular to wall and flat roses
- easy installation due to individually mountable fixing plates made of high-quality stainless steel for hanging the support rail
- rose diameter 3 1/8 inch (80 mm), cap 1/2 inch (13 mm)
- includes non-corroding HEWI fixing material
- maximum loading capacity 250 lbs (113 kg)
- made from high-grade synthetic material in the HEWI colors 99 (pure white), 95 (stone gray), 92 (anthracite gray), 90 (jet black), 86 (sand), 84 (umber) and 33 (ruby red)
- meets the requirements of 2010 ADA standards and ICC/ANSI A117.1-2017
- straight rail with supports straight to the wall and roses
- for holding onto and as a support
- with corrosion-protected steel core throughout
- length 24 inch (610 mm), rail diameter of rail 1 5/16 inch (33 mm), 2 13/16 inch (71 mm) deep
- wall connection with discreet supports perpendicular to wall and flat roses
- easy installation due to individually mountable fixing plates made of high-quality stainless steel for hanging the support rail
- rose diameter 3 1/8 inch (80 mm), cap 1/2 inch (13 mm)
- includes non-corroding HEWI fixing material
- maximum loading capacity 250 lbs (113 kg)
- made from high-grade synthetic material in the HEWI colors 99 (pure white), 95 (stone gray), 92 (anthracite gray), 90 (jet black), 86 (sand), 84 (umber) and 33 (ruby red)
- meets the requirements of 2010 ADA standards and ICC/ANSI A117.1-2017
