{650 mm wide, gushing edge, with concealed gripping edge
Article number 950.13.101}
HEWI Washbasin
made of mineral composite with non-porous surface, alpine white, with gushing edge to wall, with shelf and deep rectangular basin with generous radii and concealed gripping edge, without overflow, prepared for single hole mixer tap, wheelchair accessible to DIN 18040 and ÖNORM B1600/1601, weight capacity to EN 14688, 650 mm wide and 565 mm deep, CE and UKCA marking according to Construction Products Regulation No. 305/2011, for hanger bolt fixing.
Show more
made of mineral composite with non-porous surface, alpine white, with gushing edge to wall, with shelf and deep rectangular basin with generous radii and concealed gripping edge, without overflow, prepared for single hole mixer tap, wheelchair accessible to DIN 18040 and ÖNORM B1600/1601, weight capacity to EN 14688, 650 mm wide and 565 mm deep, CE and UKCA marking according to Construction Products Regulation No. 305/2011, for hanger bolt fixing.
EAN
4014885560111
Fitting preparation
for single hole mixer tap
Kind
- Accessible washbasins (gushing edge)
- Accessible washbasins (modular)
Washbasin width
650 mm
Washbasin
- made of mineral composite material with non-porous surface
- with gushing edge to wall
- with shelf and deep rectangular basin with generous radii
- with concealed gripping edge
- wheelchair accessible to DIN 18040 and ÖNORM B1600/1601
- 650 mm wide, 565 mm deep
- wash trough depth 100 mm
- prepared for single hole mixer tap
- without overflow
- loading capacity to EN 14688
- prepared for single hole mixer tap
- CE and UKCA marking according to Construction Products Regulation No. 305/2011
- made of mineral composite material with non-porous surface
- with gushing edge to wall
- with shelf and deep rectangular basin with generous radii
- with concealed gripping edge
- wheelchair accessible to DIN 18040 and ÖNORM B1600/1601
- 650 mm wide, 565 mm deep
- wash trough depth 100 mm
- prepared for single hole mixer tap
- without overflow
- loading capacity to EN 14688
- prepared for single hole mixer tap
- CE and UKCA marking according to Construction Products Regulation No. 305/2011
Design awards
Awarded by
Downloads
| 2D drawing | DXF | |
| 3DF | DXF | |
| Product data sheet | ||
| Performance declaration | ||
| Cleaning and Care Instructions |
Documents
| Colour Chart | Link |
