Article number 160XA.3000G7
HEWI System 162 Pull Handle
Straight handle with indented oblique supports for mounting on frame doors The handle fulfils the guidelines of the German Federal Association of Accident Insurance Funds (Bundesverband der Unfallkassen e. V. - BUK) - safe distance from the closing edge 25 mm, stainless steel, Surface satin finished, handle length within range from 300 mm to 2299 mm, made of round tube 30 mm diameter, 1.5 mm wall thickness, for one-sided and paired (double-sided) fixing.
Recommendation! When ordering please clarify dimensions and/or features and options
Show more
Straight handle with indented oblique supports for mounting on frame doors The handle fulfils the guidelines of the German Federal Association of Accident Insurance Funds (Bundesverband der Unfallkassen e. V. - BUK) - safe distance from the closing edge 25 mm, stainless steel, Surface satin finished, handle length within range from 300 mm to 2299 mm, made of round tube 30 mm diameter, 1.5 mm wall thickness, for one-sided and paired (double-sided) fixing.
Recommendation! When ordering please clarify dimensions and/or features and options
Diameter handle
30 mm
Support shape
oblique
Basic colour of the push handle
stainless steel look
Material
Stainless steel
Stainless steel pull handle
System 162 made of a tube (1.4301) diameter 30 mm, 1.5 thick, for one-sided and paired fixing on glass, wooden, PVC and metal doors (aluminium: 1 to 3-chamber, steel: 1 chamber profiles),
Load bearing capacity under alternating load 100 kg on wooden and metal doors, 50 kg on PVC doors, with 2 fixing points, fixing outside the lock area or within the lock area, as well as fixing through the lock.
Straight handle with indented oblique support posts prepared for mounting on frame doors. The handle fulfils the guidelines of the German Federal Association of Accident Insurance Funds (Bundesverband der Unfallkassen e. V. - BUK) - safe distance from the closing edge 25 mm.
Surface satin finished
State required handle length within range from 300 mm to 2299 mm
System 162 made of a tube (1.4301) diameter 30 mm, 1.5 thick, for one-sided and paired fixing on glass, wooden, PVC and metal doors (aluminium: 1 to 3-chamber, steel: 1 chamber profiles),
Load bearing capacity under alternating load 100 kg on wooden and metal doors, 50 kg on PVC doors, with 2 fixing points, fixing outside the lock area or within the lock area, as well as fixing through the lock.
Straight handle with indented oblique support posts prepared for mounting on frame doors. The handle fulfils the guidelines of the German Federal Association of Accident Insurance Funds (Bundesverband der Unfallkassen e. V. - BUK) - safe distance from the closing edge 25 mm.
Surface satin finished
State required handle length within range from 300 mm to 2299 mm
Downloads
| Fixing types | ||
| Fixing types | ||
| Product data sheet | ||
| Assembly note |
Documents
| Ausschreiben.de | Link | |
| Colour Chart | Link |
Pull handle
Article number 160XA.3000G7
