{Article number 111XAH01.110}
HEWI Standard door fitting
in H-technology according to DIN 18255 and EN 1906 made of stainless steel, Surface satin finished, consisting of: lever handle 111XAH, diameter 21.3 mm, backplate, short 230.21XAH, with integrated spring-assisted restraining "hold-up" module.
The lever handle meets the standards of EN 179 and DIN 18040.
user category: Class 4
Recommendation! When ordering please clarify dimensions and/or features and options
Show more
in H-technology according to DIN 18255 and EN 1906 made of stainless steel, Surface satin finished, consisting of: lever handle 111XAH, diameter 21.3 mm, backplate, short 230.21XAH, with integrated spring-assisted restraining "hold-up" module.
The lever handle meets the standards of EN 179 and DIN 18040.
user category: Class 4
Recommendation! When ordering please clarify dimensions and/or features and options
holding-up spring
YES - with spring
DIN Direction
Left/Right
EAN
4014885255505
Nachhaltigkeit
EPD
article number EAN
111XAH01.110
Perforation
BB - multicoloured beard
Square
8,5 mm
Distance
72 mm
Technology
H-technology | Class 4
Door thickness
38,1 - 48,0 mm
Floor to wall stationary support
Backplate, short
Material
Stainless steel
Fitting type
Standard door fittings
Standard door fitting
in H-technology with backplates according to DIN 18255 and EN 1906 made of stainless steel, consisting of:
Lever handle 111X... made of stainless steel tube (1.4301), diameter 21.3 mm with 1.5 mm wall thickness, with stepped shoulder guide and groove, with set screw M5 as additional fixing of lever and spindle, for optimal transfer of force to door leaf.
The lever handle meets the standards of EN 179 and DIN 18040.
Installed by simply latching the lever handle into the base parts preassembled on the door. The latching can be released using the dismantling tool.
backplate 230.21X... composite synthetic material and steel substructure with black zinc/nickel surface for optimum corrosion protection, integrated spring-assisted restraining "hold-up" module, can be used for left or right-hand opening doors, supporting the lock for longer durability. Fixed rotating bearing of the lever handle with automatically latching all-round locking and 5 mm journal as maintenance-free plain bearing with elastic compensating area, to cancel the possible mounting inaccuracies. Concealed, non-loosening screwed joint with M5 stainless steel screw and sleeve combination as well as the pivot disappearing into the leaf.
Backplate cap made of stainless steel (1.4301), 45 x 170 mm, 10.5 mm high, 1.5 mm wall thickness.
Surface satin finished
Designed and tested for the projects segment, user category to EN 1906 - Class 4 fitting with spindle 8 - 8.5 mm
user category: Class 4
Durability: Class 7
Door weight: No classification specified
Fire resistance: Class 0
Safety: Class 1
Corrosion resistance: Class 4
Burglary protection: Class 0
Design-type: A
Sustainability: EPD Environmental Product Declaration
in H-technology with backplates according to DIN 18255 and EN 1906 made of stainless steel, consisting of:
Lever handle 111X... made of stainless steel tube (1.4301), diameter 21.3 mm with 1.5 mm wall thickness, with stepped shoulder guide and groove, with set screw M5 as additional fixing of lever and spindle, for optimal transfer of force to door leaf.
The lever handle meets the standards of EN 179 and DIN 18040.
Installed by simply latching the lever handle into the base parts preassembled on the door. The latching can be released using the dismantling tool.
backplate 230.21X... composite synthetic material and steel substructure with black zinc/nickel surface for optimum corrosion protection, integrated spring-assisted restraining "hold-up" module, can be used for left or right-hand opening doors, supporting the lock for longer durability. Fixed rotating bearing of the lever handle with automatically latching all-round locking and 5 mm journal as maintenance-free plain bearing with elastic compensating area, to cancel the possible mounting inaccuracies. Concealed, non-loosening screwed joint with M5 stainless steel screw and sleeve combination as well as the pivot disappearing into the leaf.
Backplate cap made of stainless steel (1.4301), 45 x 170 mm, 10.5 mm high, 1.5 mm wall thickness.
Surface satin finished
Designed and tested for the projects segment, user category to EN 1906 - Class 4 fitting with spindle 8 - 8.5 mm
user category: Class 4
Durability: Class 7
Door weight: No classification specified
Fire resistance: Class 0
Safety: Class 1
Corrosion resistance: Class 4
Burglary protection: Class 0
Design-type: A
Sustainability: EPD Environmental Product Declaration
